LYZ-10 Outdoor Iron Smart City Light Pole

About Ningbo Liaoyuan Lighting Group Co.,ltd

LYZ-10

City monitoring
Pixel 200W   focal length 4. 8-115mm, 23 times optical   Operating temperature 30℃+65℃
Video compression H265/H. 264/MJPEG power supply DC12V 18W max Working humidity Temperature less than 90%
Resolution and frame rate Support up to 1920*1080@ 30fps HD picture Vertical range -15° ~90° (automatic flip) Protection level 1P66: TVS 4000V lightning protection, anti-surge, anti-surge, in line with GB/T17626.54 standard
Minimum illumination Color 0.005Lux @(F1.6, AGC ON) Horizontal range 360° monitoring without dead ends Local storage Maximum support 256G
Digital zoom 16 times Infrared irradiation distance 100 metres

Smart lighting
LED type High power 3535/5050, medium power 3030   Power factor >0.9   Service life >30000h
Rated power string 60W-300W Main light color temperature 3000~4500 Working temperature -20℃~+50℃
Input voltage AC220±20% Color rendering index ≥Ra70≥ Working environment humidity 10%~90%
Frequency Range 50/60Hz Main lighting effect (Lm/ 130 Protection level IP65

Wireless WIFI
wireless technology 802.11N/2T2R 300M MI MO   Operating mode Gateway mode/AP mode/Universal relay mode   Working environment humidity 5%~90%
working frequency 2. 4GHz Blue radius 150 meters Power consumption 8W
Transmission speed string 300mbps Maximum standby 32 days power supply Support 24VPOE power supply
Flash memory 16M flash memory 128M large memory Working ring block temperature -20℃~+50℃ Features Wireless connections

Environmental monitoring
Meteorological elements Wind speed. Wind direction, temperature, humidity, pressure PM10, PM2.5   Operating Voltage Dc12~30V (Power consumption: 25mA@12V)   Multiple transmission RS485
PW2.5 accuracy ±10‰0-500ug/m PM10 accuracy ± 10 ‰ @ 0-1000ug / m 3

City radio
power 30W   Noise ratio ≥70dB   power supply DC24V
Protocol ARP, UDP, TcP/iP, IGMP audio format WAV (8K.22K). MP3 (32kbps-192kbps) Operating temperature -10℃~+70℃
Audio input sensitivity 0.775V Sampling Rate 8K Working humidity 10%~90%
Frequency response 50Hz-15KHz(±3B) Harmonic distortion ≤0.3X

Information Release
Module resolution P3. 84   Maximum power 800W/unit   Protection level IP65
Display size 800mm*1500mm Average power 240W/set Service life 100000h
Overall size 900mm*1700mm*90mm Input power AC100-240V/50-60Hz Operating temperature WC ~ + 5 (TC
brightness 7000CD/m2 way to control 3G.4G/WIFI remote cluster control Working humidity 10%~90%

One key alarm
Network protocol TCP/IP UDP. I GMP. RTP   MIC input sensitivity 10mV   Working humidity 10%~90%
Audio sampling rate 16K-48KHZ Signal to noise ratio ≥90dB Working voltage DC 14V
Broadcast audio format MP3. WAV camera 500W pixels Power consumption 6W
Audio mode 16 stereo CD sound quality Operating temperature -20℃+60℃

Smart charging pile
rated power 7kw   Start method Swipe card. AP scan code   Working environment humidity 10%~90%
charging method AC single charge Protection level ≥IP54 appropriate types new energy vehicles
Input voltage Ac220V±10% Working environment -30℃~+50℃

Liaoyuan Group is leading LYZ-10 Outdoor Iron Smart City Light Pole company and LYZ-10 Outdoor Iron Smart City Light Pole suppliers in China. Liaoyuan has been certificated of ISO9001 QMS, ISO 14001 EMS and OHSMS, and Liaoyuan also passed a series of authoritative certification including GS, CE, ENEC, UL. You can wholesale LYZ-10 Outdoor Iron Smart City Light Pole easily from us.

Company Profile

About Ningbo Liaoyuan

Ningbo Liaoyuan Group established in 1984, it is becoming an international well-known outdoor lighting and special steel pole production enterprises, involved in lighting, power distribution,communication, new energy and other fields. The headquarters of Ningbo Liaoyuan Lighting Industry Company Limited is located in Ningbo, Zhejiang, with three subsidiaries including Süd Solar GmbH(Germany), Liaoyuan Group Lighting(Beijing) Co., LTD. and Ningbo Liaoyuan Municipal Engineering Co., Ltd.
The company is located in South Section,Yuyao Economic Development Zone,Yuyao,Zhejiang,covering an area of 236,000 square meters and owning registered capital of RMB30 million.Company owns 800 staffs,including more than 500 technical person.The company mainly produces and sells high-power LED street lights,high bay lights,explosion-prooflights,500 watts flood lights,tunnel lights,garden lights,landscape,power pole,communication pole,4-pipe tower and other products.The company has formed relatively complete product system.Also it has the annual production capability of 700,000 sets of high power green lights.After nearly 30 years of the industry accumulation,Liaoyuan has established marketing and service network which covering mare than 40 provices and cities nationwide.our customers are in more than 70 countries and regions of the world.Company established good cooperative relationship in research with institions such as Fudan,Tsinghua,Zhejiang University and China.Jiliang University.We have more than 130 patents,,including invention patents,utility model petents and design patents,and we are the “Zhejiang patent demonstration enterprises”.
Liaoyuan has been certificated of ISO9001 QMS,ISO 14001 EMS and OHSMS,and Liaoyuan also passed a series of authoritative certification including GS,CE ENEC,UL.lt is processing ahead to a top brand in intelligent lighting industry,company is one member of the top 100 enterprises in ningbo manufacturing.
Liaoyuan Group has 1-level construction qualification in city and road lighting.lt has emerged a large number of Key projects,such as Hongkong-Zhuwan-Macao Bridge project,Hangzhou Bay Bridge project,Ningbo EMC project,Nanning EMC project,Qingdao Chongqing road project,Hanzhou zijinggang tunnel,Yunnan wukun tunnel project,Mazhao tunnel project,Guangzhou road project,Suzhou jiangyingangcheng road solar energy project,Germany,Netherlands LED road project,Dubai solar energy project, Guinea(Africa) solar energy project, Benin(Africa) solar energy project,Alston(Australia) LED road project.

Company adhering to build a ”century Liaoyuan",company constructs the core competitiveness in the lighting industry,by recruiting talents,,creating international brands,and inplementing the strategy of open innovation.etc.And also our company formed a strategic alliance with Cree (United States),Philips(Netherlands) and Samsung(Korea),in order to being the world's green lighting product development and prodction base.

Company Profile

Ningbo Liaoyuan Lighting Industry Co., Ltd.
Ningbo Liaoyuan Group is the largest road lighting and special steel pole production enterprise in China, with 3 subsidiaries including Ningbo Liaoyuan Lighting Technology Co., LTD., Ningbo Liaoyuan Lighting Co.,LTD.,and Liaoyuan(anshan) Industry Co., LTD. Group company owns 1,000 staffs , including more than 500 technical person and more than 50 person with senior professional titles. Ningbo liaoyuan Lighting Co., LTD., covers an area of 130,000 square meters, with registered capital of RMB 105 million, and Liaoyuan(anshan) industrial Co., LTD., covers an area of 210,000 square meters, with total investment of RMB 300 million and registered capital of RMB 40 million

Company Video ▲
Liaoyuan has been certificated of ISO 9001 QMS,ISO 14001 EMS and OHSMS,and Liaoyuan also passed a series of authoritative certification including GS,CE ENEC,UL.It is processing ahead to a top brand in intelligent lighting industry,company is one member of the top 100 enterprises in ningbo manufacturing.
Company adhering to build a ”century Liaoyuan”,company constructs the core competitiveness in the lighting industry,by recruiting talents,creating international brands, and implementing the strategy of open innovation,etc.And also our company formed a strategic alliance with Cree (United States),Philips(Netherlands) and Samsung(Korea),in order to being the world's green lighting product development and production base.

Office Base ▲
Liaoyuan Group has 1-level construction qualification in city and road lighting.It has emerged a large number of Key projects,such as Hongkong-Zhuwan-Macao Bridge project,Hangzhou Bay Bridge project,Ningbo EMC project,Nanning EMC project,Qingdao chongqing road project,Hanzhou zijinggang tunnel,Yunnan wukun tunnel project,Mazhao tunnel project,Guangzhou road project,Suzhou jiangyingangcheng road solar energy project,Germany,Netherlands LED road project,Dubai solar energy project, Guinea(Africa) solar energy project, Benin(Africa) solar energy project,Alston(Australia) LED road project.

Liaoyuan Main Entrance ▲
  • How Long Can I Get The Feedbacks After We Sent The Inquiry?
    We will reply you within 12 hours in working day.
  • What Products Can You Offer?
    We mainly produce lamps and poles, lamps can be divided into traditional high pressure sodium lamps and LED lamps, which can be subdivided into five types of lamps, poles, including power pole, power tower, communication rod, communication tower, power structure.
  • What Applications Do Your Products Relate To?
    Our products cover a wide range of industries including train & railway, automobile & truck, construction machinery, mining machinery, forklift, agricultural machinery, shipbuilding, petroleum machinery, construction, valve and pumps, electric machine ,hardware, power equipment and so on.
  • Can You Do Customized Products?
    Yes,we produce standardized lamp poles and their accessories.
  • How About The Capacity Of Your Company?
    We have 5 new automatic lighting assembly line, Million purification patch shop and two poles manufacturing center, including two automatic spraying lines, a lamp aluminum die-casting workshop, a finishing workshop and a solar street lamp assembly workshop, annually producing more than 200,000 tons of special steel, and more than 700,000 sets of lamp.
  • How Many Employees Of Your Comany?What About The Technicists?
    We now have more than 500 employees, including 30 engineers and 100 technicians.
  • How To Guarantee The Quality Of Your Goods?

    Firstly,we will do the inspection after every process.For the finished products,we will do 100% inspection according to the customers’ requirements and the international standard.

    We then have advanced and complete top-of-the-line inspection equipment in our industry: spectrum analyzer, metallographic microscope, universal tensile testing machine, low temperature impact testing machine, X-ray inspection machine, magnetic particle inspection machine, ultrasonic flaw detector, CMM, Measuring instrument and so on. The above-mentioned equipment can fully guarantee to provide customers with high-precision finished parts of finished products, and at the same time, it can meet the customers' all requirements of physical and chemical properties, non-destructive testing and high-precision geometric size testing.

  • What’S The Payment Term?
    When we quote for you,we will confirm with you the way of transaction,FOB,CIF,CNF,etc. For mass production goods, you need to pay 30% deposit before producing and70% balance against copy of documents.The common way is by T/T. L/C is also acceptable.
  • How To Deliver The Goods To Us?
    Usually we will ship the goods to you by sea,because we are in Ningbo,and we are only 90 kilometers away from the Ningbo Port,it is very convenient and efficient to ship goods to any other countries. Of course, if your goods are very urgent,the Ningbo Airport and Shanghai Airport are also very nearby.
  • Where Are Your Products Mainly Exported To?
    Our products are mainly exported to Brazil, Chile, Germany, Spain, Italy, the United Kingdom, Russia, Australia, the Netherlands, Saudi Arabia, Guinea and other dozens of countries.
  • Are You a Direct M,anufacturer or a Trading Company?

    Our company is a brand with a long history of manufacturers, followed by Beijing Rongjing design company, Germany, Germany, Sola Ltd. as a European-oriented marketing and technology services company, we also have our own international trade sector, we produce Since the sale.

  • Can You Make Custom Products?

    Yes, we do custom products, we develop and produce products based on drawings or samples provided by our customers. Or design ideas to the customer to solve the overall smart city design

  • Where Are Your Products Mainly Exported To?
    Our products are mainly exported to Brazil, Chile, Germany, Spain, Italy, the United Kingdom, Russia, Australia, the Netherlands, Saudi Arabia, Guinea and other dozens of countries.

Company Profile

Ningbo Liaoyuan Group established in 1984, it is becoming an international well-known outdoor lighting and special steel pole production enterprises, involved in lighting, power distribution,communication, new energy and other fields. The headquarters of Ningbo Liaoyuan Lighting Industry Company Limited is located in Ningbo, Zhejiang, with three subsidiaries including Süd Solar GmbH(Germany), Liaoyuan Group Lighting(Beijing) Co., LTD. and Ningbo Liaoyuan Municipal Engineering Co., Ltd.
The company is located in South Section,Yuyao Economic Development Zone,Yuyao,Zhejiang,covering an area of 236,000 square meters and owning registered capital of RMB30 million.Company owns 800 staffs,including more than 500 technical person.The company mainly produces and sells high-power LED street lights,high bay lights,explosion-prooflights,500 watts flood lights,tunnel lights,garden lights,landscape,power pole,communication pole,4-pipe tower and other products.The company has formed relatively complete product system.Also it has the annual production capability of 700,000 sets of high power green lights.After nearly 30 years of the industry accumulation,Liaoyuan has established marketing and service network which covering mare than 40 provices and cities nationwide.our customers are in more than 70 countries and regions of the world.Company established good cooperative relationship in research with institions such as Fudan,Tsinghua,Zhejiang University and China.Jiliang University.We have more than 130 patents,,including invention patents,utility model petents and design patents,and we are the "Zhejiang patent demonstration enterprises".

Certificate


Environmental Management   Quality Control   Occupational Health and Safety Management

Send Us Message
